FEATURES
Pulse Bar graph
Plethysmogram
Multi-language
Store/Review Patient SpO2 & PR Trend
Spot/Monitor Mode
Record Patient Name
Patient Type Selection
Data access via USB port
Probe Fault & Presence Detection
Adjustable Volume & Backlight
Nellcor Compatible SpO2 sensor
SPECIFICATIONS SPO2
Range : 0~100%
Accuracy : ±2%（70%~100%） / Undefined （0~69%）
Resolution : .1%
PI
Range : .0~20%
Accuracy : Undefined
Resolution : 0.001%
PR
Range : 25~250bpm
Accuracy : ±3bpm
Resolution : 1bpm
RR
Range : 5~150rpm
Accuracy : +2 rpm
Compliance
Main Standard : ISO 80601-2-61:2011
Package Content and Options
Included: SatLite Plus Device, Adult SpO2 Finger Clip Sensor,
Rechargeable Lithium Battery, USB Cable.
Optional: USB 5V Power Supply Adapter, Additional SpO2
sensors, Dock, Silicon Protection, TEMP and ECG functions.
ECG (Optional – Some models only- Non CE Cert)
Range : 0.15mV-5.5mV
Accuracy : .2.36uV/LSB
Resolution : Undefined
HR (Optional – Some models only – Non CE Cert)
Range : 13~300bpm
Accuracy : ±1bpm
Resolution : 1bpm
TEMP (Optional – Some models only – Non CE Cert)
Range : TBD ˚C
Accuracy : ± TBD ˚C
Display
Size and Type : 3.2”Touchscreen TFT
Languages : English, French, German, Polish, Spanish, Russian
Simplified & Traditionnal Chinese, Portugese
Buttons : 6 soft silicon buttons
Interfaces and Power Supply
DB9 Connector for Nellcor compatible SpO2 Sensor
USB Port for 5V power charging and data export:
Built-in and Replaceable Lithium battery for up to 12h continuous
operation.
DOWNLOADS Click to download
