FEATURES
Body TEMP measurement (34.0 ~ 43°C / 93.2 ~ 109.4°F)
Object/Surface TEMP measurement (0 ~ 100°C / 32 ~ 212°F)
Fast measurement in 1 sec
Measurement distance from 1 to 5cm
Auto power Off
Works with 2 x AAA batteries (type LR03)
Ultra light with only 90grs
CE Standard compliant and certified
Temperature unit selectable (degree Celsius or Fahrenheit)
Selection of body or surface measurement
50 memories
SPECIFICATIONS
Environmental characteristics
Operating Conditions
Temperature: 15°C ~ 40°C (59°F ~ 104°F)
Humidity: ≤ 85%, non-condensation
Atmospheric pressure: 70.0kPa ~ 106.0kPa
Storage/Transport Conditions
Temperature: -20 ~ 55°C (-4 to 131°F)
Humidity: ≤ 93%, non-condensation
Atmospheric pressure: 70kPa ~ 106.0kPa
Electrical and Mechanical characteristics
Battery
1.5V (AAA), Alkaline battery x 2 (IEC Type LR03)
Mechanical
Dimensions: 138 x 95 x 40mm (LxWxH)
Weight: 90g (without accessories)
Interfaces
HMI
Four buttons: Set, up and down buttons, fire
Display: LCD, with 3 background color according to temperature measured
Display shows temperature, unit, measurement mode and icon indicating if temperature is acceptable
Offset adjust of +/- few degrees
Battery level indicator • Beep indicator
Memory indication
Performances
Thermometry
Rated Output Range:
Body mode: 34.0 ~ 43.0°C / 93.2 ~ 109.4°F
Surface mode: 0 ~ 100°C / 32 ~ 212°F
Laboratory Accuracy in Body Mode:42.1:
34.0 ~ 34.9°C: ±0.3°C / 93.2 ~ 94.8°F : ±0.5°F
35.0 ~ 42.0°C: ±0.2°C / 95.0 ~ 107.6°F : ±0.4°F
43.0°C: ±0.3°C / 107.8 ~ 109.4°F : ±0.5°F
Laboratory Accuracy in Surface Mode: ±2°C / ±3.6°F
Display Resolution : 0.1°C / 0.1°F
Three-color Backlight:
34.0 ~ 37.3°C / 95.9 ~ 99.1°F : Green backlight (Normal Temperature)
37.4 ~ 38.0°C (Alarm point) / 99.3 ~ 100.4°F : Yellow backlight (Slight Fever)
38.1 ~ 43.0°C / 100.6 ~ 109.4°F : Red backlight (High Fever)
(Note that for surface mode, the backlight is always Green color.)
Auto Power Off Time: ≤ 18s
Measuring Time: ≤ 2s
Measuring Distance: 1 ~ 5cm (0.4 ~ 2in)
Memories: 50
Standard Compliance
Safety standard: EN 60601-1:2006+A1:2013, EN 60601-1-2:2015
Front Panel and Case Labeling: EN ISO15223-1:2016
Temperature Measurement: EN ISO80601-2-56:2017
Home Healthcare Environment: EN 60601-1-11:2015
IP22
ORDERING INFORMATION
Model #TD-IRPRO : IR Contactless Thermometer
