Mechanical and Environment
・Dimensions： 60 x 47 x 43 mm (2.36 x 1.85 x 1.69 inches)
・Weight： ~80 g (complete device with batteries), < 350grs with transport pouch.
・Mechanical robustness： Meets the shock and vibration requirements for transport of SS-EN ISO 21647:2004 clause 21.102
・Temperature and Humidity： Operating: -5 to 50ºC, 10 to 90% RH, non-condensing Storage: -30 to 70ºC, <90% RH, non-condensing
・Atmospheric pressure： 70 - 120 kPa
EtCO2 Measurement
・Transducer Type： Mainstream CO₂ Monitor
・Measuring method： Dual-wavelength, non-dispersive infrared spectroscopy
・Initialization Time： Capnogram, displayed within few seconds at an ambient temperature of 25ºC, and full specifications within 1-2 minutes especially if temperature below 15ºC
・CO2 Measurement Range： 0 to 99 mmHg, 0 to 9.9%, 0 to 9.9 kPa
・CO2 Accuracy： ±(0.2% + 2% of reading)
・Total system response time： < 1s
・Calibration： No routine user calibration required. An airway adapter zero is required when changing to a new airway adapter
・Recovery time after defibrillator test: Unaffected
Respiration Rate Measurement
・Respiratory rate Range： 0~150 Breaths Per Minute (BPM)
・Respiration Rate Accuracy： ±1BPM
・Breath detect： Adaptive threshold, minimum 1 % CO₂ change
・Airway Adapters： < 5 cc dead space (adult/Pediatric), < 1 cc dead space( infant)
Human Machine Interface
・Display： Active OLED color graphic display, 65 000 colors, 128 x 128 pixels Multi-languages(English, French, Italian, Hungarian, polish and more to be supported)
・Front Panel Buttons： 4 buttons: power on/off, up/down selection
・Alarms： No Adapter, Clogged Adapter, No Breath Detected, High AwRR, Low ETCO2, High ETCO2, Temperature out of range, Atmospheric pressure is over operating range, Low Battery
Power Specifications
・External Supply： None
・Power Consumption： TBD
・Batteries： Two AAA Cell batteries (2x1.5VDC): Alkaline IEC:LR03 or Energizer Ultimate Lithium L92 batteries. Use of other Lithium batteries may present a risk of fire or explosion
・Battery life： Duracell Plus Alkaline: ~4 hours Energizer Ultimate Lithium L92: ~7 hours
Regulatory Compliance
・Certificate： CE
・Standards compliance：MDD 93/42/EEC EN 60601:1990, Amendment 1 (1991), Amendment 2 (1995) EN 60601-1-2:2001 EN 60601-1-8:2004 EN ISO 21647:2004 EN ISO 5356-1:2004 EN 1789:2007
・Box content： RICap capnograph, adult and neonate airway adapters, lanyard and pouch
