OPTIONAL
FEATURES
Multi-scene Application:
Bediside monitoring
Operating room
Emergency
Easy To Use:
Night done
Trend data record
Bluetooth transmission
Humanized User-interface
SPECIFICATIONS
SPO₂
Measurement range 0~100%
Measurement accuracy ±2%（70%~100%）Undefined （＜70%）
Measurement resolution 1%
PR
Measurement range 25~250bpm
Measurement accuracy ±3bpm
Measurement resolution 1bpm
EtCO₂
Measurement range 0~20vol%
Measurement accuracy 0~12 vol%：±(0.2vol%+2%of reading） 12~20vol%：±(0.2vol%+6%of reading）
Measurement resolution 1mmHg
AwRR
Measurement range 0~150rpm
Measurement accuracy ±1rpm（0~70rpm）Undefined （within other ranges）
Measurement resolution 1rpm
TEMP
Measurement range 0~50℃
Measurement accuracy ±1℃
Measurement resolution 0.1℃
Operating Environment
Operating humidity 15%~95%RH,non-condensing
Operation temperature 0℃~40℃
Power Supply AC100~240V(±10%）(50/60HZ) ± 3HZ , 60VA
Physical Paramter
Dimensions 80x45x180mm
Measurement accuracy ＜2kg(Without accessories)
Measurement resolution ≥ 45 dB
Regulatory Compliance
Standards compliance IEC 80601-2-61:2017
IEC 80601-2-56:2017
IEC 80601-2-55:2018
IEC 80601-2-A1:202
DOWNLOADS
SatPro Series Handheld Vital Signs Monitor.pdf
